Specifications
| Product Dimension: | 8 x 4.5 x 2.4 inch (203 x 114 x 60 mm) (Charger only) |
| Product Weight: | 3.6 lb (1657 g) |
| Input: | 100-120VAC, 50-60Hz, 300W |
| Output: | 12.9VDC 15.0A, 25.6V DC 7.5A |
| Charging Voltage: | 12VDC, 24VDC |
| Charging Current: | 15A (12VDC), 7.5A (24VDC) |
| Reverse Current: | <5mA |
| Low Voltage Detection: | 3.75V (12VDC), 15.5V (24VDC)* |
| Low Voltage Detection (Push Mode): | 0.5V (12VDC) |
| Operating Temperature: | 32°F - 104°F / 0°C - 40°C |
| Storage Temperature: | -4°F - 140°F / -20°C - 60°C |
| Battery Types: | Standard Lead-Acid (Wet Cell / Flooded, SLA & Maintenance Free) AGM, GEL, Lithium-ion ( incl. LiFePO₄ ) |
| Battery Capacity: | Up to 250Ah 12V batteries, maintains all battery sizes. Up to 120Ah 24V Lead Acid Battery, maintains all battery sizes. |
| IP Rating: | IP68 Water-resistant |
| Package Contents: | 1. 1 x Battery Charger 2. 1 x User Guide |
